Product Details
| Properties | Data |
| Type | Single Cylinder |
| Cooling | Water |
| Crankshaft thread | M18 x 1.5 |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 12.5 bar |
| Mounting | Flange mounting |
| Operating speed | 3000 (1/min) |
| Piston diameter | 85 mm |
| Piston stroke | 62 mm |
| Port thread 0 | M26 x 1.5 |
| Port thread 2 | M26 x 1.5 |
| Port thread 8.1 | Ø 10.2 mm |
| Port thread 9.1 | M14 x 1.5 |
| Port thread 9.2 | M14 x 1.5 |
| Type of operation | High pressure using unloader |
Comparison Numbers
| Replaces | Referans No | Alternative No |
| MAN | 51.54100.7070 | 51541007070 |
| Replaces Wabco | 912 117 000 0 | 9121170000 |
Application
| Vehicle Brand | Model, engine, gearbox, axle, cab |
| MAN Chassis | HOC |
| MAN CLA | CLA 2007 – 2018 |
| MAN D-engines | D 0834, D 0836 |
| MAN E-engines | E 0836 |
| MAN G/M/F 90 | G 90, M 90 |
| MAN Lion’s | Lion’s City, Lion’s Classic |
| MAN L/M/F/E 2000 | M 2000 |
| MAN N-Busse | NG, NL, NM |
| MAN S-Busse | SÜ |
| MAN TG-Serie | TGA 2000 – 0, TGL 2004 – 0, TGM 2004 – 0 |
| MAN ÜL-Busse | ÜL Intercity |
| Neoplan Neoplan | Centroliner |
