Product Details
| Properties | Data |
| Type | Single Cylinder |
| Cooling | Water |
| Crankshaft thread | M20 x 1.5 LH |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 12.5 bar |
| Mounting | Flange mounting |
| Operating speed | 3000 (1/min) |
| Piston diameter | 85 mm |
| Piston stroke | 62 mm |
| Port thread 0 | Ø 30 mm |
| Port thread 2 | M26 x 1.5 |
| Port thread 4 | M12 x 1.5 |
| Port thread 8.1 | Ø 6 mm |
| Port thread 9.1 | M14 x 1.5 |
| Port thread 9.2 | M14 x 1.5 |
| Type of operation | Normal pressure using unloader |
Comparison Numbers
| Replaces | Referans No | Alternative No |
| Mercedes-Benz | 906 130 1315 | 9061301315 |
| Mercedes-Benz | 906 130 4315 | 9061304315 |
| Mercedes-Benz | A906 130 1315 | A9061301315 |
| Mercedes-Benz | A906 130 4315 | A9061304315 |
| EVOBUS | A9061303015 | A9061303015 |
| DAIMLER | 9061306215 | |
| FREIGHTLINER | TDAS4123520250 | |
| KENWORTH | S412-352-025-0 | S4123520250 |
| MACK | S4123520250 | |
| MACK | 6300-4123520250 | 63004123520250 |
| MERITOR | S4123520250 | |
| PACCAR | 9500693 | |
| PETERBILT | S412-352-025-0 | S4123520250 |
| VOLVO | TDAS4123520250 | |
| VOLVO | WAB4123520250 | |
| Replaces Wabco | 412 352 025 0 | 4123520250 |
Application
| Vehicle Brand | Model, engine, gearbox, axle, cab |
| Mercedes-Benz Atego 1 | 375, 950, 952, 953, 954, 970, 972, 974, 975, 976 |
| Mercedes-Benz Atego 2 | 375, 970, 972, 974, 975, 976 |
| Mercedes-Benz Axor | 375, 950, 952, 953, 954, 958 |
| Mercedes-Benz Citaro | 628 |
| Mercedes-Benz Econic 1 | 957 |
| Mercedes-Benz Transporter | 670, 673, 674 |
| Mercedes-Benz Unimog | 405, 437 |
| Mercedes-Benz Zetros | 949 |
| Mercedes-Benz Atego | tbd |
