Product Details
| Properties | Data |
| Operating Mode | Automatic |
| Fitting Position | left |
| Toothing | SAE 1 1/2” 10 |
| alpha (deg) | 145 |
| offset | -60 |
| Position | 5 |
| inclination (deg) | -10 |
| Bore Distance [mm] | 145 |
| bushing | 14 mm |
| Number of Teeth | 10 |
| control arm | double bent (medium; R=78mm) |
| Other side | 72886C |
| Repair kit | 76046 |
Comparison Numbers
| Replaces | Referans No | Alternative No |
| DAF | 1263486 | |
| DAF | 1263486A | |
| DAF | 1263486R | |
| ZG | ZG.50744-0008 | |
| Replaces Haldex | 72887 | 72887C |
Application
| Vehicle Brand | Model, engine, gearbox, axle, cab |
| DAF 45/55/65/75/85/95 | 75 1992-1998 1992 – 1998, 85 1992-1998 1992 – 1998 |
| DAF CF | 75 CF 1998-2001 1998 – 2001, 85 CF 1998-2001 1998 – 2001, CF 75 2001-2006 2001 – 2006, CF 75IV 2006-2013 2006 – 2013, CF 85 2001-2006 2001 – 2006, CF 85IV 2006-2013 2006 – 2013 |
